Delete Catalyst SD-WAN Security Objects

You can delete one or multiple Catalyst SD-WAN security objects.

  • If the security object was synchronized with Catalyst SD-WAN Manager, its deletion will be reflected across both Security Cloud Control Firewall Management and Catalyst SD-WAN Manager to maintain consistency.

  • Any security policies or configurations referencing the deleted object do not get deleted automatically. You must remove the references manually from the security policies before deleting the object.

  • Delete actions are logged for audit purposes, ensuring traceability of changes. To view the logs:

    • In the Security Cloud Control application, choose Monitor > Events & Logs > Logs > Change Log.

    • In the Catalyst SD-WAN Manager application, choose Monitor > Logs > Audit Logs.

Before you begin

Make sure the Catalyst SD-WAN security objects you intend to delete are not being used or referenced in other objects, policies, or configurations.

Procedure

Step 1

In the left pane, choose Administration > Integrations > Catalyst SD-WAN.

Step 2

In the left pane, click Manage > Objects.

Step 3

Click the WAN Branch Edge tab.

Step 4

Check one or multiple security objects you want to delete.

Step 5

In the Actions pane on the right, click Remove.

Step 6

Click OK to confirm.

Selected Catalyst SD-WAN security objects are deleted. Delete actions are logged for audit purposes, ensuring traceability of changes.

To view the logs:

  • In the Security Cloud Control application, choose Monitor > Events & Logs > Logs > Change Log.

  • In the Catalyst SD-WAN Manager application, choose Monitor > Logs > Audit Logs.
