View malware events

The Advanced Malware Protection (AMP) events dashlet displays the counts of malicious, unknown, and clean files identified by AMP over a selected period. AMP blocks malware based on file reputation and uploads unknown files to Cisco AMP Threat Grid for further analysis.

The Top Intrusion & Malware Events dashlet on the Security Cloud Control Firewall Management dashboard is mapped to the Intrusion Prevention and Advanced Malware Protection dashlets on the Monitor page of Catalyst SD-WAN Manager on the Security tab.

Procedure

Step 1

Click Dashboard.

Step 2

Navigate to the Top Intrusion & Malware Events dashlet.

Step 3

Click SDWAN under Data Sources.

Step 4

Click the Malware Events tab.

Step 5

Select Blocked in the drop-down near the dashlet. By default, Allowed is selected.

Malware Events tab in the Top Intrusion & Malware Events dashlet displays malicious file counts over time.

Step 6

Click the event you want to view in Catalyst SD-WAN Manager.

A cross-launch window of the Catalyst SD-WAN Manager Monitor page appears.

Step 7

Navigate to the Advanced Malware Protection dashlet to view the event.
